Large Diameter Fiber Cleaver(FC-100)








Large Diameter Fiber Cleaver(FC-100)

Product Description

The FC-100 Large Diameter Fiber Cleaver is mainly designed for cleaving fibers (≤1500um) and fiber combiners. Users can easily cleave different types of fibers by simply setting the fiber tension and advancing the cutter head before cleaving. The device features the cleaving stability required for production and the flexible adjustability essential for R&D work.


Features

⚫ Built-in high-capacity lithium battery

⚫ Cleave for 125~1500μm fibers

⚫ Automatic tension control

⚫ Average blade life: 3000 cleaves


Specification

Parameter

Unit

Specification

Fiber Cladding Diameter

um

220~1500

Tension Range

gf

0~5000

Cleaving Angle

°

<0.5

Fiber Fixture Displacement Length

mm

32~80

Cutter Head Step

um

1~3

Blade Life

-

3000

(for 400μm DCF with 1250gf tension)

Working Humidity

%RH

50~60

Power Supply

-

AC 110~220V 50/60Hz; DC 12.6V 5A

Dimension(L*W*H)

mm

258×152×169



Standard Accessory List

Accessory

Model

Unit

Quantity

Large-diameter Fiber Cleaver

FC-100

set

1

Power Adapter

-

set

1

Fiber holder

FH- (Provide according to the size request)

pair

1

Certificate of Conformity

-

copy

1

Warranty Card

-

copy

1

User Manual

-

copy

1

Portable Carrying Case

-

piece

1
